PH Stainless Steel
SAE Type 630 stainless steel (more commonly known as 17-4 PH, or simply 17-4; also known as UNS 17400) is a grade of martensitic precipitation hardened stainless steel. It contains approximately 15–17.5% chromium and 3–5% nickel, as well as 3–5% copper. The name comes from the chemical makeup which is approximately 17% chromium and 4% nickel.
An alternative to nickel alloys
Using our metallurgical expertise, we continue to achieve breakthroughs in the area of duplex stainless steel, adding more specialized, higher performance products to the program.
PROPERTIES-17-4 PH STAINLESS STEEL
17-4 can be heat treated to high levels of strength and hardness, and features corrosion resistance and machinability comparable to austenitic 304 stainless. Being martensitic, 17-4 is magnetic.
17-4 is capable of being hardened up to approximately 44 Rc when heat treated to condition H900.
Over aging (aging beyond the peak strength condition) improves resistance to stress corrosion cracking.
Uses for 17-4 stainless steel include components which require high hardness and/or corrosion resistance at temperatures of up to 600 °F (316 °C). Specific applications for 17-4 include the petroleum and chemical industries, as well as use in aircraft parts.
